Denyo Mitsubishi Carter and other mainstream first tier brand generators
A full lineup to produce
optimum power
for user needs.
Generators are indispensable as power sources at construction sites. Widely used for live TV broadcasts, various types of events, leisure activities, and other purposes, our generators produce the optimal power to meet user needs. Offering high-performance power generation and durability as well as energy conservation and noise reduction, these products have won endorsement as the first choice of professionals in Japan and around the world.
| Alternator Frequency Hz | 50 / 60 |
|---|---|
| Alternator Output Rating (kVA) | Continuous - 125 / 150, Standby - 138 / 165 |
| Alternator No. Of Phases | 3-Phase, 4-Wire |
| Alternator Rated Voltage V | 2 Dual Voltage |
| Alternator Power Factor | 0.8 |
| Alternator Voltage Regulation % | Within ± 1.5 |
| Alternator Excitation | Brushless, Rotating, Exciter (With A.V.R) |
| Alternator Insulation | Class F |
| Engine Make & Model | Komatsu SAA6D102E-2-0 |
| Engine Type | Inlined, Direct Injected, Turbocharge, Aftercooled |
| Engine Output Rating kW/min⁻¹ | 113/1500 / 135/1800 |
| Engine No. of cylinders-Bore x Stroke mm | 6 - 102 x 120 |
| Engine Piston Displacement L | 5.880 |
| Engine Fuel | ASTM No. 2 Diesel Fuel or Equivalent |
| Engine Fuel consumption*2 L/h | 20.6 / 25.0 |
| Lube Oil Sump Capacity L | 22 |
| Engine Coolant Capacity L | 28.4 |
| Engine Battery × Quantity | 95D41Rx2 |
| Engine Fuel Tank Capacity L | 250 |
| Length mm | 3250 |
| Width mm | 1080 |
| Height mm | 1500 |
| Dry Weight (Full Weight) kg | 2390 |
| Sound Level 7m dB (A) 1500/1800 rpm (min⁻¹)*4 | 62.0 / 65.0 |
